| Model | IYP-12KW-A1 |
| Battery voltage | 48Vdc |
| Rated power | 12KW |
| MPPT maximum voltage | 200-650VDC |
| Protection level | IP65 |
| Size | 422*280*700mm |
| Weight | 37kg |
Support 6 units in parallel, 48V low voltage lithium battery, IP65 waterproof
Online inquiry >>
| Model | IYP-6KW-A1 |
| Battery voltage | 48Vdc |
| Rated power | 6KW |
| MPPT maximum voltage | 150-425VDC |
| Protection level | IP65 |
| Size | 330*235*580mm |
| Weight | 24kg |
Waterproof grade IP65, supports 6 units in parallel, two-way photovoltaic control
Online inquiry >>
| Model | IYP-51.2V200Ah |
| Nominal voltage | 51.2V |
| Rated capacity | 200Ah |
| Charge cut-off voltage | 54V |
| Discharge cut-off voltage | 42V |
| Communication method | RS485/CAN |
| Size | 442*420*265mm |
| Weight | 86kg |
BMS independently developed, ultra-large capacity, compatible with mainstream inverters
Online inquiry >>
| Model | IYP-51.2V100Ah |
| Nominal voltage | 51.2V |
| Rated capacity | 100Ah |
| Charge cut-off voltage | 54V |
| Discharge cut-off voltage | 39V |
| Communication method | RS485/CAN |
| Size | 442*420*133mm |
| Weight | 40kg |
BMS independently developed, compatible with mainstream inverters
Online inquiry >>
| Model | IYP-51.2V200Ah |
| Nominal voltage | 51.2V |
| Rated capacity | 200Ah |
| Charge cut-off voltage | 58V |
| Discharge cut-off voltage | 42V |
| Maximum charge current | 200A |
| Maximum discharge current | 200A |
| Communication mode | RS485/CAN |
| Size | 850*466*145mm |
| Weight | 88kg |
Large capacity of side wiring, supporting up to 15 groups in parallel
Online inquiry >>
| Model | IYP-12V200Ah |
| Nominal voltage | 12.8V |
| Rated capacity | 200Ah |
| Charge cut-off voltage | 14.6V |
| Discharge cut-off voltage | 10.0V |
| Maximum charge current | 60A/100A |
| Maximum discharge current | 150A |
| Communication method | RS485/CAN (RS232/Bluetooth optional) |
| Size | 525*240*220mm |
| Weight | 21.5kg |
Mainly used for power supply of small equipment such as RVs, camping, ships, etc.
Online inquiry >>
| Model | IYP-12V100Ah |
| Nominal voltage | 12.8V |
| Rated capacity | 100Ah |
| Charge cut-off voltage | 14.6V |
| Discharge cut-off voltage | 10.0V |
| Maximum charge current | 30A/100A |
| Maximum discharge current | 150A |
| Communication method | RS485/CAN (RS232/Bluetooth optional) |
| Size | 330*175*215mm |
| Weight | 11.5kg |
High rate and high current discharge, supports 4 groups in series
Online inquiry >>
| Model | IYP-12KW |
| Battery voltage | 48Vdc |
| Rated power | 12KW |
| MPPT maximum voltage | 150-425VDC |
| Protection level | IP20 |
| Size | 330*235*580mm |
| Weight | 31kg |
Waterproof grade IP65, two-way high-voltage photovoltaic MPPT, six units in parallel
Online inquiry >>
| Model | IYP-5.12KWh+5KW |
| Rated energy | 5.12KWh |
| Rated power | 5KW |
| MPPT voltage | 120-430VDC |
| Communication method | WiFi/RS485 |
| Protection level | IP20 |
| Size | 500*150*730mm |
| Weight | 58kg |
Lithium battery + inverter, integrated UPS, easy to install
Online inquiry >>
| Model | IYP-2.56KWh+3KW |
| Rated energy | 2.56KWh |
| Rated power | 3KW |
| MPPT voltage | 30-400VDC |
| Communication method | WiFi/RS485 |
| Protection level | IP20 |
| Size | 450*140*570mm |
| Weight | 32kg |
Lithium battery + inverter, integrated UPS, easy to install
Online inquiry >>
| Model | IYP-51.2V280Ah |
| Nominal voltage | 51.2V |
| Rated capacity | 280Ah |
| Charge cut-off voltage | 58V |
| Discharge cut-off voltage | 42V |
| Maximum charge current | 200A |
| Maximum discharge current | 200A |
| Communication method | RS485/CAN |
| Size | 485*400*837mm |
| Weight | 155kg |
Single battery can directly drive 10KW, touch display
Online inquiry >>
| Product Model | IYP-51.2V400Ah |
| Nominal Voltage | 51.2V |
| Rated Capacity | 400Ah |
| End-of-charge Voltage | 58.0V |
| End-of-discharge Voltage | 40.0V |
| Max.Charge Current | 50A/100A |
| Max.Discharge Current | 400A |
| Communication | RS485/CAN (RS232/Bluetooth optional) |
| Size | 565*460*720mm |
| Weight | 184kg (about) |
Low-voltage stacked energy storage LiFePO4 batteries are used for home energy storage, home energy storage, photovoltaic energy storage commercial energy storage, communication base stations, backup power 10KWH/15KWH/25KWh optional flexible configuration.
Online inquiry >>
| Product Model | IYP-204V50Ah |
| Nominal Voltage | 204V |
| Rated Capacity | 50Ah |
| End-of-charge Voltage | 232V |
| End-of-discharge Voltage | 159V |
| Max.Discharge Current | 50A |
| Communication | RS485/CAN（RS232/Bluetooth optional） |
| Size | 565*460*600mm |
| Weight | 100kg（about） |
High-voltage energy storage LiFePO4 batteries are used for home energy storage, photovoltaic energy storage, commercial energy storage, communication base stations, backup power supplies, etc. A single battery can directly drive a 10kw inverter. Support RS485/CAN communication, protocol can be customized
Online inquiry >>
| Product Model | IYP-51.2V400Ah |
| Nominal Voltage | 51.2V |
| Rated Capacity | 400Ah |
| End-of-charge Voltage | 58.4V |
| End-of-discharge Voltage | 40.0V |
| Max.Discharge Current | 400A |
| Communication | RS485/CAN (RS232/Bluetooth optional) |
| Size | 600*600*1165 mm |
| Weight | 187kg（about） |
| Product Model | IYP-51.2V200Ah |
| Nominal Voltage | 51.2V |
| Rated Capacity | 200Ah |
| End-of-charge Voltage | 58.4V |
| End-of-discharge Voltage | 40.0V |
| Max.Charge Current | 200A |
| Communication | RS485/CAN (RS232/Bluetooth optional) |
| Size | 475*370*315mm |
| Weight | 90kg (about） |
Floor-standing LiFePO4 batteries are used for home energy storage, photovoltaic energy storage, commercial energy storage, communication base stations, backup power, etc. Compatible with the world's mainstream 20+ inverters Support RS485/CAN communication, the protocol can be customized
Online inquiry >>
| Product Model | IYP-15KWH+5KW |
| Nominal Voltage | 51.2V |
| Rated Vapacity | 300Ah |
| End-of-charge Voltage | 58.0V |
| End-of-discharge Voltage | 40.0V |
| Max.Charge Current | 150A |
| Communication | RS485/CAN (RS232/Bluetooth optional) |
| Size | 410*231*1615mm |
| Weight | 150kg (about.) |
| PV Output Power | 7KW |
| PV Range | 120-450VDC |
| Output Power | 5KW |
The off-grid wall-mounted all-in-one machine 15KWH+5KW is a LiFePO4 battery used for home energy storage. It integrates UPS and supports wifi mode. The beautiful all-in-one machine can be configured flexibly. Mainly for European and American markets, 48V energy storage power supply systems, etc.
Online inquiry >>
| Product Model | IYP-15KWH+5KW |
| Nominal Voltage | 51.2V |
| Rated Capacity | 300Ah |
| End-of-charge Voltage | 58.4V |
| End-of-discharge Voltage | 40.0V |
| Max.Charge Current | 150A |
| Communication | RS485/CAN(RS232/Bluetooth optional) |
| Size | 231*410*1855mm |
| Weight | 160kg（about） |
| PV Output Power | 7KW |
| PV Range | 150-500VDC |
| Output Power | 5KW |
Hybrid all-in-one machine against the wall 15kwh+5kw is a LiFePO4 battery for home energy storage. It integrates UPS and supports wifi mode. The fashion all-in-one machine can be configured flexibly. Mainly for European and American markets, 48V energy storage power supply systems, etc.
Online inquiry >>
| Product Model | IYP-15KWH+5KW |
| Nominal Voltage | 51.2V |
| Rated Capacity | 300Ah |
| End-of-charge Voltage | 58.4V |
| End-of-discharge Voltage | 40.0V |
| Max.Charge Current | 150A |
| Communication | RS485/CAN (RS232/Bluetooth optional) |
| Size | 480*240*1964mm |
| Weight | 148kg |
| PV Output Power | 7KW |
| PV Range | 150-450VDC |
| Output Power | 5KW |
American standard wall-mounted all-in-one machine 15kwh+5kw is used for home energy storage, integrated UPS for home energy storage, photovoltaic energy storage, commercial energy storage, etc., supports wifi mode, beautiful all-in-one machine flexible configuration is mainly aimed at European and American markets, 48V energy storage power system wait
Online inquiry >>
| Product Model | 409V50Ah |
| Nominal Voltage | 409.5V |
| Rated Capacity | 50Ah |
| End-of-charge Voltage | 467.2V |
| End-of-discharge Voltage | 320V |
| Max.Discharge Current | 50A |
| Communication | RS485/CAN (RS232/Bluetooth optional) |
| Size | 460*565*1680mm |
| Weight | 280kg (about) |
High-voltage energy storage LiFePO4 batteries are used for home energy storage, photovoltaic energy storage, commercial energy storage, communication base stations, backup power supplies, etc. A single battery can directly drive a 10kw inverter. Support RS485/CAN communication, protocol can be customized
Online inquiry >>
| Product Model | 409V50Ah |
| Nominal Voltage | 409.6V |
| Rated Capacity | 50Ah |
| End-of-charge Voltage | 467.2V |
| End-of-discharge Voltage | 320V |
| Max.Discharge Current | 50A |
| Communication | RS485/CAN (RS232/Bluetoot |
| Size | 460*565*1680mm |
| Weight | 280kg (about) |
High-voltage energy storage 409V50Ah LiFePO4 battery is used for household energy storage, photovoltaic energy storage, commercial energy storage, communication base station, backup power supply, etc. A single battery can directly drive a 10kw inverter. Support RS485/CAN communication, protocol can be customized
Online inquiry >>
| Product Model | 51.2V500Ah |
| Nominal Voltage | 51.2V |
| Rated Capacity | 500Ah |
| End-of-charge Voltage | 58.4V |
| End-of-discharge Voltage | 40.0V |
| Max.Discharge Current | 150A |
| Communication | RS485/CAN (RS232/Bluetooth optional) |
| Size | 584*360*800mm |
| Weight | 240kg (about) |
Low-voltage stacked energy storage LiFePO4 batteries are used for home energy storage, home energy storage, photovoltaic energy storage commercial energy storage, communication base stations, backup power 10KWH/15KWH/25KWh optional flexible configuration.
Online inquiry >>
| Product Model | 48V400Ah |
| Nominal Voltage | 48V |
| Rated Capacity | 400Ah |
| End-of-charge Voltage | 54.75V |
| End-of-discharge Voltage | 37.5V |
| Max.Discharge Current | 300A |
| Communication | RS485/CAN (RS232/Bluetooth optional) |
| Size | 485*400*1025mm |
| Weight | 210kg (about) |
Standing energy storage LiFePO4 batteries are used for home energy storage, photovoltaic energy storage, commercial energy storage, communication base stations, backup power supplies, etc. A single battery can directly drive a 10kw inverter. Support RS485/CAN communication, protocol can be customized
Online inquiry >>
| Product Model | 48V300Ah |
| Nominal Voltage | 48V |
| Rated Capacity | 300Ah |
| End-of-charge Voltage | 54.75V |
| End-of-discharge Voltage | 37.5V |
| Max.Discharge Current | 300A |
| Communication | RS485/CAN (RS232/Bluetooth optional) |
| Size | 485*400*837mm |
| Weight | 155kg（about） |
Standing energy storage LiFePO4 batteries are used for home energy storage, photovoltaic energy storage, commercial energy storage, communication base stations, backup power supplies, etc. A single battery can directly drive a 10kw inverter. Support RS485/CAN communication, protocol can be customized
Online inquiry >>
| Product Model | 51.2V200Ah |
| Nominal Voltage | 51.2V |
| Rated Capacity | 200Ah |
| End-of-charge Voltage | 58.4V |
| End-of-discharge Voltage | 40.0V |
| Max.Discharge Current | 200A |
| Communication | RS485/CAN (RS232/Bluetooth optional) |
| Size | 920*550*165mm |
| Weight | 108kg(about） |
Power wall arc wall mounts are used for home energy storage, photovoltaic energy storage, commercial energy storage, communication base stations, backup power supplies, etc. Compatible with the world's mainstream 20+ inverters Support RS485/CAN communication, the protocol can be customized
Online inquiry >>
| Product Model | 51.2V100Ah |
| Nominal Voltage | 51.2V |
| Rated Capacity | 100Ah |
| End-of-charge Voltage | 58.0V |
| End-of-discharge Voltage | 40.0V |
| Max.Discharge Current | 150A |
| Communication | RS485/CAN (RS232/Bluetooth optional) |
| Size | 590*410*145mm |
| Weight | 49kg (about） |
Powerwall arc wall mounts are used for home energy storage, photovoltaic energy storage, commercial energy storage, communication base stations, backup power supplies, etc. Compatible with the world's mainstream 20+ inverters .Support RS485/CAN communication, the protocol can be customized
Online inquiry >>
| Product Model | 51.2V200Ah |
| Nominal Voltage | 51.2V |
| Rated Capacity | 200Ah |
| End-of-charge Voltage | 58.0V |
| End-of-discharge Voltage | 40.0V |
| Max.Discharge Current | 200A |
| Communication | RS485/CAN (RS232/Bluetooth optional) |
| Size | 920*550*165mm |
| Weight | 92kg (about） |
Power wall arc wall mounts are used for home energy storage, photovoltaic energy storage, commercial energy storage, communication base stations, backup power supplies, etc. Compatible with the world's mainstream 20+ inverters Support RS485/CAN communication, the protocol can be customized
Online inquiry >>
| Product Model | 51.2V100Ah |
| Nominal Voltage | 51.2V |
| Rated Capacity | 100Ah |
| End-of-charge Voltage | 58.0V |
| End-of-discharge Voltage | 40.0V |
| Max.Discharge Current | 100A |
| Communication | RS485/CANRS485/CAN (RS232/Bluetooth optional) |
| Size | 600*480*165mm |
| Weight | 49kg（about） |
Powe rwall is used for home energy storage, photovoltaic energy storage, commercial energy storage, communication base stations, backup power, etc. Compatible with the world's mainstream 20+ inverters Support RS485/CAN communication, the protocol can be customized
Online inquiry >>
